The C-Plus Series meets different cultivation needs
C-LED lamps are developed with the aim of ensuring the best possible growth of plants at different stages of development, from germination to production. C-LED lamps exploit LED technology by adopting the world's best LED qualities and components. This makes it possible to reproduce the intensity and light spectrum (light colour) required to stimulate the harmonious growth and development of the plant and to optimise the performance of the system. Tests carried out by the C-LED research and development department in cooperation with university research institutes have made it possible to develop a range of lamps capable of effectively meeting the demands of growers according to the essences cultivated and the areas of use. Different types of TOPLIGHT C-PLUS series are in production, which are similar in the lamp body but differ in the light spectrum emitted to meet different requirements:
- TOPLIGHT Greenhouse C-PLUS HORTIS
- TOPLIGHT Greenhouse C-PLUS NATURAL INDOOR
- TOPLIGHT Greenhouse C-PLUS EXTENDED WHITE
- TOPLIGHT Greenhouse C-PLUS PURPLE
Mechanical Specifications:
- Dimensions: 65x7x9cm
- Mass: 1.8 kg
- Mounting: Suspension
- Degree of protection: IP66
- Material: Aluminium lamp body; Transparent cover in UV-resistant Polycarbonate
- Working temperature: -10°C / +40°C
- Maximum lamp body temperature: 65°C @ ta=25°C
Electrical Specifications
- Power supply: 198-264V - 50 / 60 Hz
- Nominal current: 0.33A @ 230Vac
- Power consumption: 75/78 W nominal (230 Vac only)
- PF: > 0.98
- THD:< 10%
- Inrush current: 57.7A-217µs 230Vac
Optical/Performance Specifications
- Peak PPFD: Up to 81 μmol/m2s @ 1 m distance
- Average PPFD: Up to 23.3 μmol/m2s over an area of 4 m2 @1 m distance
- PPF: Up to 177 μmol/sec @ TLed = 25°C (75W version)
- Efficiency: Up to 2.4 μmol/J @ TLed = 25°C
- Beam Angle: 80°
- Number of LEDs: 42 pcs
- Average LED life: L70 > 50,000 hours
The following optional extras are included in the product package for the correct mounting of the lamp:
- 2 Terminal Metal Hooks - C-Led
- 1 Female Connector RST B1 IP68 - 3W - C-LedTap IP67 Last Lamp - C-Led
- C-Led - MAIA - Top Light Greenhouse C-PLUS 230V 75W EXTENDE lamp with cable and socket
Specifications
| LED type |
Bar LED |
| Manufacturer |
C-Led |
| Manufacturer |
C-Led |
| Watt |
75 W |
| Coulour |
White |
